OD 12.4mm 6 Circuit Slip Ring 2A Flanged For Smart Home Security Monitoring

OD 12.4mm 6 Circuit Slip Ring 2A Flanged For Smart Home Security Monitoring
OD 12.4mm 6 Circuit Slip Ring 2A Flanged For Smart Home Security Monitoring

Large Image :  OD 12.4mm 6 Circuit Slip Ring 2A Flanged For Smart Home Security Monitoring

Product Details:
Place of Origin: China
Brand Name: GUREN
Certification: ISO9001.CE.RoHS
Model Number: WX12-6PS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: ＄19-199
Packaging Details: Standard/On Request
Delivery Time: 3 weeks ARO
Supply Ability: 1K units/week
Contact Now Chat Now

OD 12.4mm 6 Circuit Slip Ring 2A Flanged For Smart Home Security Monitoring

Description
Installation: Flange Installation Outer Diameter: 12.4mm
Length: 13.2mm Brush Wire Technology: Brushed Gold Plating
Crosstalk Suppression: -60dB@1MHz Signal Bandwidth: DC~10MHz
Highlight:

12.4mm slip ring with flange

,

6 circuit slip ring for smart home

,

2A flanged slip ring

Product Overview

The WX12-6PS is a flange-type electrical slip ring featuring 6 line channels, each capable of transmitting 2A current.

Key Features
  • 360° signal transmission capability for current, video, HD signals, control systems, network cables, and servo motors
  • Military-grade super-hard gold plating on contact points ensures minimal resistance fluctuations and extended service life
  • Engineered for low torque, minimal loss, reduced electrical noise, and maintenance-free operation
  • Compact 12.4mm outer diameter design
  • Integrated structure for easy installation
Technical Specifications
Parameter Value
Dielectric strength 300VCA@50Hz,60s
Insulation resistance ≥500MΩ/300VDC
Dynamic resistance change value ＜10mΩ
Rated voltage 0～240VDC/VAC
Wire Specifications 28AWG Teflon wire
Wire length Rotor 250mm; stator 250mm
Operating temperature -20℃～+80℃
Operating humidity 0～85%RH
Protection level IP51
Shell material Engineering Plastics
Rotational torque 0.05N.m,+0.01N.m/6-way
Service life 2 million rpm
Product Dimensions

Product Images
OD 12.4mm 6 Circuit Slip Ring 2A Flanged For Smart Home Security Monitoring 0 OD 12.4mm 6 Circuit Slip Ring 2A Flanged For Smart Home Security Monitoring 1 OD 12.4mm 6 Circuit Slip Ring 2A Flanged For Smart Home Security Monitoring 2
Applications
Drones Stabilizers Smart Homes Security Monitoring Photography Equipment Videography Equipment Robotics Testing Instruments Turntables Automation Equipment
