8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing

8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing
8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing
8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing 8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing 8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing 8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing 8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing 8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing

Large Image :  8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing

Product Details:
Place of Origin: China
Brand Name: GUREN
Certification: ISO9001.CE.RoHS
Model Number: SX56F-58P-GRA0389
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: ＄19-199
Packaging Details: Standard/On Request
Delivery Time: 3 weeks ARO
Payment Terms: L/C,D/A,D/P,T/T
Supply Ability: 1K units/week
Contact Now Chat Now

8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing

Description
Outer Diameter: 56mm Length: 154.2mm
Signal Support Types: Analog Video Signal 、USB 2.0 、Ethernet Signal、 Low-speed Digital Signal、 Analog Signal Signal Bandwidth: DC~10MHz
Crosstalk Suppression: -60dB@1MHz Service Life: 20 Million Rpm
Highlight:

8-way electric slip ring with flange

,

5A 50-way slip ring aluminum housing

,

2A flange slip ring 250rpm speed

8-Way 5A 50-Way 2A Flange Electric Slip Ring
High-Density Multi-Channel Rotary Connector
This 58-way flange slip ring features an outer diameter of 58mm with 58 electrical channels: 8 channels capable of 5A current and 50 channels handling 2A current. The anodized aluminum alloy housing provides IP51 protection and excellent heat dissipation, supporting rotation speeds up to 250 rpm with a maximum voltage of 220V.
Key Features
  • Multi-Channel Design: 58 independent electrical channels (8*5A + 50*2A) for simultaneous power and signal transmission
  • Compact Construction: 58mm outer diameter with flange mounting for easy integration in space-constrained applications
  • Durable Housing: Anodized aluminum alloy provides corrosion resistance and IP51 protection against dust and vertical dripping
  • High-Speed Performance: Rated for continuous operation at 250 rpm with low rotational torque (0.05N.m)
  • Extended Service Life: Rated for 20 million rotations with stable dynamic resistance (<0.1Ω)
Technical Specifications
Parameter Value
Dielectric strength 300VCA@50Hz,60s
Insulation resistance ≥500MΩ/300VDC
Dynamic resistance change value ＜0.1Ω
Rated voltage 0～220VDC/VAC
Wire Specifications AWG22#, AWG26# Teflon wire
Wire length Rotor 300mm; stator 300mm (reference value)
Operating temperature -30℃～+80℃
Operating humidity 0～85%RH
Protection level IP51
Shell material Aluminum alloy
Rotational torque 0.05N.m,+0.01N.m/6-way
Service life 20 million rpm
Product Dimensions
8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing 0
Dimensional diagram of 58-way flange slip ring
Product Views
8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing 1
Front view showing contact arrangement
8-way 5A 50-way 2A flange electric slip ring 250rpm speed, aluminum alloy black housing 2
Side view with flange mounting detail
Typical Applications
This high-density slip ring is ideal for automated robotic rotary joints, precision testing equipment, medical rotary instruments, semiconductor processing equipment, drones, stabilizers, smart home devices, security monitoring systems, photography/videography equipment, robotic systems, test instruments, turntables, and other automation equipment requiring reliable multi-channel power and signal transmission during continuous rotation.
